Specifications
| Range of product | Sepam series 20 Sepam series 40 Sepam series 48 Sepam series 80 NPP Sepam series 80 Sepam series 60 |
|---|---|
| Device short name | ACE959 |
| Communication port protocol | Modbus RTU network: E-LAN interface: RS485 – 4-wire Modbus RTU network: S-LAN interface: RS485 – 4-wire |
|---|---|
| Local signalling | LED for link activity (front face) |
| [Us] rated supply voltage | 12 V DC tolerance: +/- 10 % 24 V DC tolerance: +/- 10 % |
| Maximum supply current | 16 mA: receiving mode 40 mA: maximum in sending mode |
| Mounting mode | Fixed |
| Mounting support | Symmetrical DIN rail |
| Height | 88 mm |
| Width | 144 mm |
| Depth | 30 mm |
| Product weight | 0.2 kg |
